Mobile Thermal Printers

• Print Method: Thermal Line Printing
• Resolution: 203 × 203 dpi
• Print Speed: 100 mm/s
• Paper: 58 mm (57.5 ± 0.5 mm) width × Ø18–40 mm, thickness 50–75µm
• Print Width: 384 dots
• Barcodes Supported: UPC-A/E, EAN-8/13, Code39, Code93, Code128, GS1-128, ITF, Codabar, GS1 DataBar
• 2D Codes Supported: PDF417, QR Code, MaxiCode, Data Matrix, Aztec, GS1 Composite
• Interfaces:
    • Bluetooth Model: USB-C + Bluetooth 5.0
    • Wi-Fi Model: USB-C + Wi-Fi 5.0
• Battery: Lithium-ion, USB-C charging (Full charge ~3 hrs @ 5V/3A)
• Battery Life: Up to 27 hrs (Bluetooth), 15 hrs (Wi-Fi)
• Durability: IP54 dust/liquid resistant, Drop rating 2.1 m
• Reliability: 10 million lines; 50 km printhead life; 16 million lines MCBF
• Dimensions (W×D×H): 79 × 120 × 46 mm
• Weight: ~216 g
• Operating Temp: –15 to 50 °C (Normal); 0–40 °C while charging
• Humidity: 10–90% RH
• Supported OS / SDK: Windows, Android, iOS; ePOS SDK for mobile integration

Mobile Thermal Printers

• Print Method: Thermal Line Printing
• Resolution: 203 × 203 dpi
• Print Speed: 170 mm/s
• Paper: 79.5 mm width × Ø18–51 mm, thickness 50–75µm
• Print Width: 576 dots (48 columns) / 546 dots (42 columns)
• Barcodes Supported: UPC-A/E, EAN-8/13, Code39, Code93, Code128, GS1-128, ITF, Codabar, GS1 DataBar
• 2D Codes Supported: PDF417, QR Code, MaxiCode, Data Matrix, Aztec, GS1 Composite
• Interfaces:
    • Bluetooth Model: USB-C + Bluetooth 5.0
    • Wi-Fi Model: USB-C + Wi-Fi 5.0
• Battery: Lithium-ion, USB-C charging (Full charge ~2.5 hrs @ 5V/3A)
• Battery Life: Up to 47 hrs (Bluetooth), 25 hrs (Wi-Fi)
• Durability: IP54 dust/liquid resistant, Drop rating 1.9 m
• Reliability: 10 million lines; 50 km printhead life; 16 million lines MCBF
• Dimensions (W×D×H): 105 × 138 × 57.6 mm
• Weight: ~379 g
• Operating Temp: –15 to 50 °C (Normal); 0–40 °C while charging
• Humidity: 10–90% RH
• Supported OS / SDK: Windows, Android, iOS; ePOS SDK for mobile integration

Kiosk Thermal Printers

• Print Method: Thermal line printing
• Resolution: 203 × 203 dpi
• Print Speed: Up to 250 mm/s
• Paper:
    • 79.5 ± 0.5 mm (W) × Ø83 mm
    • 57.5 ± 0.5 mm (W) × Ø83 mm (with guide)
• Print Width: 576 dots
• Fonts: ANK A (12×24), ANK B (10×24), ANK C (9×17), Kanji A (24×24)
• Character Set: 95 Alphanumeric, 18 International, 128 × 43 Graphic
• Barcodes Supported: UPC-A/E, EAN-8/13 (JAN), Code39, Code93, Code128, ITF, Codabar, GS1-128, GS1 DataBar
• 2D Codes Supported: PDF417, QR Code, MaxiCode, Data Matrix, Aztec, GS1 Composite
• Interfaces: USB + Serial
• Buffer: 45 bytes or 4 KB
• Power: DC 24V ±5%, External PS-180; Operating ~24.2W
• Reliability:
    • Printer Mechanism Life: 17 million lines
    • Auto Cutter Life: 1.5 million cuts
    • MCBF: 65 million lines
    • MTBF: 360,000 hours
• Durability: Tamper-prevention covers, paper exit bezel option, kiosk mounting brackets
• Dimensions (W×D×H):
    • Standard: 127 × 127 × 131.2 mm
    • With Bezel: 127 × 127 × 155.9 mm
• Weight: ~1.3 kg
• Indicators: Blue LED (Power), Orange LED (Error/Paper Out)

POS Thermal Printers

• Print Method: Thermal line printing
• Resolution: 203 × 203 dpi
• Print Speed: Up to 300 mm/s
• Paper:
    • 79.5 ± 0.5 mm (W) × Ø83 mm
    • 57.5 ± 0.5 mm (W) × Ø83 mm (with guide)
• Print Width: 576 dots (80mm) / 420 dots (58mm)
• Fonts: ANK 12×24 / 10×24 / 9×17; Kanji 24×24 / 20×24 / 16×16
• Character Set: 95 Alphanumeric, 18 International, 128 × 43 Graphic
• Barcodes Supported: UPC-A/E, EAN-8/13 (JAN), Code39, Code93, Code128, ITF, Codabar, GS1-128, GS1 DataBar
• 2D Codes Supported: PDF417, QR Code, MaxiCode, Data Matrix, Aztec, GS1 Composite
• Interfaces:
    • USB-B ×1, USB-A ×2, USB-PD ×1, Ethernet ×1
    • Built-in Wi-Fi and Bluetooth 5.0 (on specific model)
• Buffer: 4 KB
• Power: DC 24V ±7%, AC Adapter (PS-190)
• Power Consumption: Operating 30.6 W, Standby 1.4 W
• Reliability:
    • Printer Mechanism Life: 17 million lines
    • Auto Cutter: 2.2M partial cuts / 1.5M full cuts
    • Thermal Printhead Life: 150 km
    • MCBF: 65 million lines
    • MTBF: 360,000 hours
• Durability: Antibacterial, water-resistant design
• Dimensions (W×D×H): 127 × 128 × 130 mm
• Weight: ~2.2 kg
• Indicators: Blue LED (Power, Interfaces), Orange LED (Error, Paper Out)

POS Thermal Printers

• Print Method: Thermal line printing, 203 dpi
• Print Speed: Up to 250 mm/s
• Fonts: 9×17 / 12×24; Thai font: 9×24 / 12×24
• Paper: 79.5 ± 0.5 mm width × Ø83 mm, thickness 0.06–0.07 mm
• Interfaces: USB + UIB (Serial / Parallel / Ethernet)
• Buffer: 4 KB or 45 bytes
• Reliability:
    • Mechanism life: 17M lines
    • Auto cutter: 1.7M cuts
    • MCBF: 65M lines
    • MTBF: 360,000 hours
• Power: DC 24V (PS-180 adapter), ~2.0 A operating
• Dimensions (D×W×H): 194 × 125 × 114 mm
• Weight: ~1.7 kg

Color Label Printers

• Print Technology: PrecisionCore TFP with Auto Nozzle Check
• Print Resolution: Up to 1200 × 1200 dpi
• Print Speed: Up to 100 mm/s (300 × 600 dpi)
• Print Width: Max 108 mm
• Ink System: UltraChrome DL pigment inks (CMYK + Matte Black or Gloss Black option)
• Media Types: Plain, matte, glossy, textured, synthetic, wristbands
• Media Handling: Roll-fed or fanfold; external roll Ø101.6 mm
• Interfaces: USB 2.0, Ethernet, optional Wi-Fi
• Barcode Support: 1D & 2D symbologies (UPC, EAN, Code128, QR, DataMatrix, Aztec, etc.)
• Display: 2.7” color LCD for status and ink monitoring
• Power Consumption: Printing ~28.2 W, Standby ~2.6 W
• Dimensions (D × W × H): 283 × 310 × 285 mm
• Weight: ~13 kg

Industrial Label Printers

• Print Method: Thermal Transfer & Direct Thermal
• Resolution / Speed Options:
    • 203 dpi @ 14 ips or 6 ips
    • Optional 300 dpi @ 8 ips or 6 ips
    • Optional 600 dpi @ 4 ips
• Max Print Width: 104 mm
• Max Print Length: 2,286 mm (203 dpi); 1,524 mm (300 dpi)
• Media Width Range: 25 mm – 120 mm
• Media Thickness: 80 µm – 250 µm
• Media Roll Diameter: up to 10-inch outer diameter
• Ribbon Options: Wax, resin, or mixed; ribbon length up to 600 m; width 30 – 110 mm; core diameter 1 inch
• Interfaces (Standard): USB Type B, 3 × USB HOST, Serial, Ethernet
• Interfaces (Optional): Wi-Fi, Parallel Port, Applicator Interface, RFID (UHF) Reader/Encoder
• Display / Controls:
    • Bravo: 3.5-inch color touch display
    • Bingo / Bravo-L: 3.5-inch non-touch color display
• Sensors: Print mechanism off, ribbon off, media off, thermal over-temperature, seam/punched label/black label positioning, motor over-temperature
• Memory: 512 MB RAM; 256 MB Flash
• Optional Accessories: Peeler, Cutter, Label Liner Rewinder
• Dimensions: 460.4 × 263.6 × 330.5 mm
• Weight: ~12.5 kg
• Security / Certifications: CE, FCC, CCC, CB, UL, RoHS, WEEE

Mobile Thermal Printers

• Print Method: Direct Thermal
• Resolution: 203 dpi
• Print Speed: Up to 80 mm/s
• Max Print Width: 72 mm (576 dots)
• Interfaces:
    • Micro-USB (standard)
    • Bluetooth 4.0 / BLE / 2.1 + EDR (Dual Mode)
    • Optional Wi-Fi (802.11 b/g/n)
• Display: 1.3-inch OLED
• Memory: 32 MB RAM / 256 MB flash
• Sensors:
    • Cover open detection
    • Out-of-paper detection
    • Gap detection (transmission, fixed middle)
    • Black mark detection (reflective, right side)
    • TPH temperature detection
• Supported Paper Widths: 55–80 mm (or 37–63 mm)
• Maximum Paper Roll Diameter: 57 mm
• Battery: 7.4 V, 1800 mAh
• Durability / Environment:
    • Protection: IP42
    • Drop test: 1.5 m
    • Operating temp: 0 °C to 55 °C; Storage: –10 °C to 65 °C
    • Humidity: 10–85% RH (no condensation)

Barcode Thermal Printers

• Print Method: Thermal transfer / Direct thermal
• Resolution: 203 dpi or 300 dpi (auto-recognition)
• Print Speed: Up to 5 ips (203 dpi) / 4 ips (300 dpi)
• Print Width: 108 mm (203 dpi) / 106 mm (300 dpi)
• Print Length: Up to 2286 mm (203 dpi) / 1524 mm (300 dpi)
• Ribbon: 300 m (wax, wax-resin, resin)
• Media Width: 25.4 – 118 mm
• Media Thickness: 60 – 250 μm
• Memory: 128 MB RAM, 256 MB Flash
• Interfaces: USB, Ethernet (optional Wi-Fi / Bluetooth)
• Barcodes: 1D & 2D (QR, PDF417, DataMatrix, etc.)
• Sensors: Gap, black mark, ribbon-out, paper-out, cover open, print head temperature
• Software: BarTender UltraLite; drivers for Windows, Linux, MacOS
• Dimensions: 293 × 237 × 180 mm
• Weight: 2.8 kg

POS  Thermal Printers

• Print Method: Direct thermal line printing
• Resolution: 203 dpi (8 dots/mm), emulated 180 dpi
• Print Speed: Up to 260 mm/s
• Print Width: 80 mm (58 mm optional)
• Interfaces: USB + Serial + Ethernet; optional Bluetooth or Wi-Fi; Cash drawer port
• Memory: 4MB RAM, 4MB Flash
• Fonts: GBK (24×24), ASCII (9×17, 12×24), 46 codepages
• Barcodes: 1D (UPC-A/E, EAN-8/13, Code39, ITF, Codabar, Code128, Code93), 2D (PDF417, QR Code)
• Graphics: Bitmap printing, max 64K each (total 256K)
• Sensors: Paper out, near end, cover open
• LED Indicators: Power (blue), Paper (orange), Error (red)
• Reliability: TPH life 150 km, Cutter life 2 million cuts
• Paper: Thermal paper, width 58/80 mm, thickness 0.056–0.1 mm, max Ø83 mm roll
• Paper Handling: Front or top loading, partial/full cut
• Power Supply: AC 100–240V input, DC 24V/2.5A output
• Dimensions / Weight: 134.8 × 132 × 132 mm; 1.37 kg (without roll)

POS Thermal Printers

• Print Method: Direct thermal printing
• Resolution: 203 dpi
• Print Speed: Up to 200 mm/s
• Print Width: 72 mm
• Interfaces: USB + Ethernet + Cash drawer (optional Wi-Fi / Bluetooth)
• Memory: 4MB RAM, 4MB Flash
• Fonts: Font A (12×24), Font B (9×17), Chinese (24×24), International sets
• Barcodes: 1D (UPC-A/E, EAN-8/13, Code39, ITF, Codabar, Code128, Code93), 2D (QR Code, PDF417)
• Sensors: Paper out, cover open, cutter jam, over-temperature
• Indicators: Built-in buzzer; optional external buzzer
• Reliability: TPH life 100 km, Cutter life 1 million cuts
• Paper: Thermal receipt/recycled thermal paper, max 80 mm width, Ø80 mm roll
• Paper Handling: Front exit
• Power Supply: AC 100–240V input, DC 24V/1.5A output
• Dimensions / Weight: 145 × 123.5 × 121.6 mm (W × D × H)
• Environment: 0–45 °C, 25–85% RH operating; –20–60 °C storage

AWB Thermal Printers

• Print Method: Direct thermal
• Resolution: 203 dpi (8 dots/mm)
• Print Speed: Up to 150 mm/s
• Print Width: Max 108 mm
• Print Length: Max 300 mm
• Processor: 32-bit RISC CPU
• Memory: 2 MB RAM / 2 MB Flash
• Media Types: Folded paper, roll paper, die-cut label, black mark paper
• Media Size: 50–110 mm width, 60–220 µm thickness, max Ø127 mm roll
• Detection: Label edge, gap, black mark, out-of-paper, cover open
• Interfaces: USB, Bluetooth
• Barcode Support: 1D (Code 39, Code 93, Code 128, etc.), 2D (QR Code)
• Fonts: Bitmap fonts (8×16, 12×24), up to 10× enlargement, 4-way rotation
• Control Panel: Power button, Feed button
• Power Supply: DC 24V / 1.5A
• Dimensions: 180 × 79 × 65 mm
• Weight: 440 g
• Durability: Enhanced print head coating for long life
• Operating Temp: 5–40 °C; Storage –20–50 °C
• Humidity: 30–85% RH (operating), 10–90% RH (storage)
• Certifications
: CCC, FCC, CE, SRRC
